Building Instructions

Dwell is a car built with a LEGO MINDSTORMS EV3 set. It uses the medium motor for powering the back wheel and one more medium motor for rotating the front wheels and thus turning. Of course, there is a differential at the back.

These are instructions on how to build the:

• Crane

for the FIRST LEGO League 2019-2020 City Shaper Challenge.

You can find more building instructions and tips and tricks about the competition on this page.

Winter might be far away or it might just be coming - depending of course on where you are in the world. But you can always spend a few hours having fun with a LEGO Mindstorms Snowmobile. A really challenging construction that requires good preparation, concentration and a lot of efforts to complete. Same is going to the mountain in the winter. But the reward at the end is worth it.

This is an attachment is designed for Luly, small LEGO Education SPIKE Prime competition robot with 3D building instructions. On a robot most of the time you place attachments on the front/side/top. These instructions show how to build an attachment that could be placed on the front of the robot. The idea is to demonstrate the principle and you can expand and build a more specific attachment for the mission that you are accomplishing. Check the courses in which this attachment is used for more information and tutorials on how to use it.

This is a carabiner attachment for taking loops. It is built with LEGO Education SPIKE Prime parts and it demonstrates how to successfully take loops. The goal of the attachment is to lock the loop after it catches it. The attachment is designed for Luly, small LEGO Education SPIKE Prime competition robot with 3D building instructions

These are building instructions for Overload Centrifuge training machine built with LEGO WeDo 2.0

This robot extends the Tetrix Box Robot chassis for FTC competitions with an additional arm. The arm could be used for lifting and placing objects and could be quite useful.

There is a special rubber band at the end of the arm, because there are not enough parts in the Tetrix set and we had to use a rubber band. But the principle of the arm is interesting, useful and you should be familiar with it - the arm keeps the motors always in the right orientation.

This is an pinless robot attachment designed for taking loops. It's built with LEGO Education SPIKE Prime parts and it demonstrates how to collect a loop while moving with the robot. The attachment is designed for Luly, small LEGO Education SPIKE Prime competition robot with 3D building instructions. There are other attachment that are designed for taking a loop and locking it so that it does not fall, but they are more complex. Search for 'Carabiner' at FLLCasts.com

Background

For rovers in other worlds, getting stuck is definitely not okay! Teams of rovers can help each other, but a lone rover needs to be very careful.

Mission

The robot or whatever agent-craft it sends out needs to cross the craters model completely, by driving directly over it. Not near it. Not around it.

Scores

• Robot or agent-craft crossed the craters model completely: 20
• Possible scores: 0, 20

Scoring Requirements

• All weight-bearing features of the crossing equipment must cross completely between the towers. > Only allowed method. Must be observed by the referee.
• The crossing must be from east to west, and make it completely past the flattened gate. > Only allowed method. Must be observed by the referee.

(mission descriptions source: https://www.first-lego-league.org/)

This LEGO Mindstorms Attachment has three gears, one frame and two axles. The goal of the attachment is to use the gears to change the direction in which the motion is transferred.

This is the forth type of an active geared attachment. "Active" means that is is power by a motor. "Geared" means that it uses gears. "Reusable" means that you can easily extend the attachment with additional parts - eg - you can reuse it. It shows a basic principle of how power is transferred between different axles that have different orientation in space - like when one of the axles is horizontal and the other is vertical. It's built with LEGO Education SPIKE Prime parts and could be used in competitions in robotics like FIRST LEGO League/World Robotics Olympiad and others. It's designed for Luly, small LEGO Education SPIKE Prime competition robot with 3D building instructions. Check the courses in which this attachment is used for more information and tutorials on how to use it.

This is an attachment that could be easily detached after a mission is accomplished. It's built with LEGO Education SPIKE Prime parts and it demonstrates an important principle for building attachments for robotics competitions like FIRST LEGO League/World Robotics Olympiad and others. You move with the robot, you complete the mission and you leave the attachment on the field when the mission is completed. In this way you save time when adding the attachment as it is most of the time pinless and takes a fraction of a second to put it. The attachment is designed for Luly, small LEGO Education SPIKE Prime competition robot with 3D building instructions. Check the courses in which this attachment is used for more information and tutorials on how to use it.

A hand-driven Ferris wheel for a cascade scene—something like the famous Ferris wheel moment from the movie Le Boulet.

Or imagine a story where... a chicken fights two hunters and sets off an explosion so powerful that the shockwave launches the chicken to the top of the highest cabin, while the hunters are blown so far away they don't even appear in the thumbnail! Or... well, yeah, I remember a story...

Just open your mind to the strangest and most unusual story you can imagine.

Estimated weekly playtime with a good story: ~2–3 hours.
