Building Instructions

We designed this field to closely resemble the intermediate level of line-following fields used by the "Arab Robotics & AI Association" in multiple competitions.

We designed this field to closely resemble the easiest level of line-following fields used by the "Arab Robotics & AI Association" in multiple competitions.

We designed this field to closely resemble the hard level of line-following fields used by the "Arab Robotics & AI Association" in multiple competitions.

We designed this field to closely resemble the hardest level of line-following fields used by the "Arab Robotics & AI Association" in multiple competitions.

This is Kriket. Kriket is an example for a Box robot assembled form LEGO Education SPIKE Prime and could be used during competition like FIRST LEGO League to achieve a smooth, repeatable behaviour of the robot. In fact. this is why it was designed. The goal of Kriket is to be a "Box Robot" and to allow for attachments to be glided on top of it. Check the courses for Kriket to understand more about how it could be used.

The robot requires a few more parts than the standard LEGO Education SPIKE Prime + Extension sets, but it is worth purchasing and having them

We took a stab at building a box robot entirely with chains. It is difficult to find these chains. They were part of the original LEGO MINDSTORMS NXT Robots, but we had an idea. Can we power the whole box robot and all the attachments with the chains. This allows us to do a nice demonstration when and how chains could be used.

To build the robot you will need about 180 of these the chain pars - 3711a. They could be found from NXT and from some technic sets.

This robots require additional parts on top of the LEGO Education SPIKE Prime and LEGO Education SPIKE Essentials. Check out the additional parts required.

This attachment is accomplishing four missions from the FIRST LEGO League 2023-2024. It is for the Chain Monster Robot. It solve mission 3 - Immersive Experience. It partially solves mission 14 - Audience delivery and mission 15 - Expert delivery by delivering Izzy the Skateboarder to the Skate Park and Emily the Visual Effects Director in Cinema.

Thinking about box robots with LEGO Education SPIKE Prime, Boxver is a good example. It is tiny, kind of small and has the brick in a vertical position. Two motors at the front. The goal of this robot is to achieve reliability and consistency of the behavior of the robot.

The Sports Utility Vehicle box robot is the new marvelous box robot that we've created. It is designed for teams that would like to learn how to build balanced, stable and working robot chassis following our box principle. It is smaller and easier to build than box robot 1 and it is more simple than box robot 2.

The main advantages of this robot compared to previous box robots are

 - motors in the right direction, so when rotating the motor forward, the robot moves forward.

 - it is much easier to attach attachments. There are 4 different gears on which you could attach attachments.

 - it has a large clearance - which means that it could move over obstacles.

Of course, it has a Gyro and two Color Sensors.  Not only that, but we have all the cables shown in the construction.

When not to use this robot?

The SUV Box robot is design to be used with a Gyro sensor and two Color Sensors for alignment. It is not working well for following lines as the sensors are very high and they are very high to allow for high clearance of the chassis. If you need to follow lines we recommend the Dominator X-Y robot

Attachments:

 - [How NOT To] Build An Active Attachment For SUV Box Robot

 - Simple Pinless Attachment for the SUV Box Robot

 - SUV Front Active Attachment for Box Robot

 - Attachments Frame for SUV Box Robot

This incredibly compact SPIKE Prime Box Robot is made for competitions like FIRST LEGO League (FLL) and World Robotics Olympiad (WRO). Whakatae (from Maori's word "whakataetae", which means "competitive") is long 17 LEGO units and is with a width of 15 LEGO units. In front of the wheels it has two color sensors which it uses to align. Whakatae also has two Large motors for moving and has two medium motors for attachments! The best part is that in order to build this SPIKE Prime Box robot you only need the Base set, a Large motor and a color sensor.

Dominator is a compact LEGO Mindstorms EV3 Box robot from the family of the Roller Coaster and Kiddo box robots. Similar to the previous two robots, Dominator also can move its front part up, down, left and right. This robot also has the same length of movement as its two predecessors of this type - 8 LEGO pins on the side and up.

The difference is that Dominator has fewer parts and has a perfect center of weight that allows it to use large attachments and lift heavy objects without threatening its stability. The movement on the X and Y axes has the same gear ratio. The light sensors are attached to the movable part of the robot which enables it to both follow a line and recognize the color of various object with height lower than 7 LEGO units.

Luly is a new STEAM competition robot from LEGO Education SPIKE Prime. We would use in some of the courses. It's simple, it requires a really small number of parts and we can demonstrate most of the attachments and programs with it. Check out the courses below and see how Luly is used to complete in a competition.

Second part of the building instructions for this LEGO Mindstorms EV3 competition robot chassis
